0402 Series

Product Introduction

Product	Size	Color	λd(nm)/	Vf(V)		IV(mcd)		Viewing	IF
	(LWHmm)		CCT(K)/					Angle	(mA)
			CIE(X,Y)					2θ1/2
				Min	Max	Min	Max	(deg)
002.R000	1.00.50.45	Red	618-640	1.7	2.2	100	120	120°	5
002.G000	1.00.50.45	Greed	512-525	2.7	3.2	28.5	450		5
002.B000	1.00.50.45	Blue	460-470	2.7	3.2	180	450		5
002.O000	1.00.50.45	Orange	600-610	1.9	2.3	40	355		5
002.Y000	1.00.50.45	Yellow	580-595	1.9	2.3	40	355		5
002.YG000	1.00.50.45	Yellow Greed	565-575	1.9	2.3	11.5	90		5
002.W000	1.00.50.45	Cool White	5000-6500	2.6	3.2	160	300		5
002.W000	1.00.50.45	Warm White	2700-3500	2.6	3.2	160	300		5
002.W000	1.00.50.45	White	4000-4500	2.6	3.2	270	410		5
002.W000	1.00.50.45	White	6500-12000	2.6	3.2	270	410		5
002.W000	1.00.50.45	White	12000-25000	2.6	3.2	270	410		5
002.W000	1.00.50.45	White	100000	2.6	3.2	270	410		5
